FLUIDMASTER IN-WALL CISTERNS & WC FRAMES

Find a Store

Fluidmaster 187-747 0.82m WC Cistern and Frame

The Fluidmaster 187 concealed cistern with frame offers an innovative solution for smaller spaces. The design allows fitting of the frame under windows or key bathroom features, whilst retaining full usability and operation.

The range of attractive plates can be mounted on the front or on top of the cistern providing ultimate flexibility for installation.

The 187 cistern features the silent Fluidmaster 747 valve; designed for ultra-simple maintenance and long-lasting performance.

Product Features
Technical Information
  • Water saving 6 / 3 litres
  • Silent operation - Only The Best Inside Fluidmaster 747 fill valve
  • Attractive range of flushing plates designed for front or top mounted application
  • Compact solution for fitting into smaller spaces
  • System fully insulated with polystyrene for long-lasting performance
  • 200mm adjustable height
  • 1/2" water connection
  • WRAS approved
  • Pre-assembled wall fixings
  • Pre-installed isolating valve
  • Order Number

    674541

  • Warranties and certifications
    10 years warranty, 25 years parts availability, 400 KG, CE, WRAS
  • Application
    Wall-hung WC pan
  • Material
    Steel
  • Self-bearing construction
    Yes
  • Surface protection
    Coated
  • Adjustable height
    YES
  • Adjustable width
    NO
  • Adjustable depth
    YES
  • Adjustable toilet height
    NO
  • Height
    820 - 1020 mm
  • Width
    500 mm
  • Depth
    150 - 210 mm
  • Cistern Model
    187
  • Cistern Material
    Plastic
  • Mains Water Connection
    External thread
  • Size of mains water threaded connection (inch)
    1/2"
  • Minimum flushing water quantity
    3 Litres
  • Maximum flushing water quantity
    6 Litres
  • Adjustable water volumes
    YES
  • Mechanical activation plate compatible
    YES
  • Pneumatic activation plate compatible
    NO
  • Touchless/IR activation plate compatible
    NO
  • Front activation
    YES
  • Top activation
    YES
  • Minimum shelf height
    820 mm
  • With shut-off valve
    YES
  • Pre-assembled
    YES
  • Supplied with pan connector
    YES
  • Supplied with contact sound insulation set
    NO
  • Supplied with toilet attachment materials
    YES
  • WRAS / KIWA certified
    WRAS
